Pass box is used to transfer material from one clean area to another clean area. Bio air clean technologies are offering the wide range of Static Pass box and Dynamic Pass Box which are made with high quality of steel. This Static Pass Box is also known as a Passive box.
Bio air clean technologies Pass Box is a closed steel box with a double door used for transferring the material from the nonsterile door to a sterile door inside the cleanroom. Scientist uses Air showers to pass through into the cleanroom where material uses pass boxes to get into the cleanroom. Pass through Box is cleanroom equipment designed in two categories one is a static pass box and the other is a dynamic pass box. Pass boxes provide a controlled environment to the cleanroom from airborne cross-contamination for a better research environment.
Airborne particles on the material may affect the research of a company so we always recommend pass box to all our pharmaceutical clients. We are a manufacturing CE certified Pass-through box with high-quality steel & suitable class Hepa filters and pre-filters. We believe in new designs, quality & great after-sales support to all clients with a year warranty and ten years of spare parts availability.
Dynamic Pass Box:
We design Dynamic Pass Box equipment in complete Stainless steel 304 with an interlocking system, UV light, Illumination light, Fan Motor, 0.3 microns HEPA filter & pre-filters. Hepa Filters are suction filters made as per European standards to prevent any kind of cross-contamination. The interlocking system will give the advantage of opening one door at a time during the pass-through of material. Class 100 & Class 1 cleanroom users always prefer a dynamic pass box instead of a static pass box.
Static pass box
Static pass box is a passive pass box designed with UV light, interlocking system, magnetic door locking & buzzer alarm; it has no HEPA filters and Fans for passing through of material. We are a renowned Manufacturer & supplier of ISO & CE certified Pass box worldwide at the best price with great after-sales support and ten years of spare parts availability. Our all products come with one year warranty and user-friendly operations and maintenance. We design pass boxes in many different sizes from the basic model of 2 ft x 2 ft x 2 ft to a large model of 8 ft x 5 ft x 5 ft. We never hesitate in customization so send your all queries of any size to our mail id.
Specification
- Constructed with a Double Wall Feature
- Three Side Wall Structure
- Door Drop Seal
- Covings for cleaning
- Switches for Door releasing on either side
- Electro Magnetic Locking System
Accessories
- HEPA Filter
- SS Handles and SS Hinges
- Indicators on both sides.
- UV Light Presence
- Fluorescent Lamp
- Audio Alarm
Specifications
| Model | BACT | BACT |
|---|---|---|
| Design type | Dynamic | Static |
| Cleanliness level | Class 100 | Passive |
| Internal Dimension | 2 x 2 x 2 Ft. 3 x 3 x 3 Ft. 4 x 3 x 3 Ft. |
2 x 2 x 2 Ft. 3 x 3 x 3 Ft. 4 x 3 x 3 Ft. |
| Construction | SS 304 | SS 304 |
| Illumination | LED | LED |
| Air system | MS Blower | Not Applicable |
| Filters | The HEPA filter (99.97%)0.3 microns-filters (95% down to 5 microns) | Not Applicable |
| Door | Interlocking Doors with Glass view Window | Interlocking Doors with Glass view Window |
| Standard Fittings | Light indicators for door Handles & hinges, UV light | Light indicators for door, SS Handles & hinges, UV light |
| Power supply | 220 V +/- 10% , 50/60 Hz | 220 V +/- 10% , 50/60 Hz |
